A new model exists for this item:
RIVER mosel
PMOSEL
Item no.: PAN02PRO
Guarantee: 60 months
EAN: 4049521169342
Sliding scale: 1
Unit: Piece
Packaging unit: 1
Series:Palmer Box Tools
Item highlights:
- First-class active DI box
- Unbalanced XLR input
- 3-way attenuator (-10, -20, -30dB)
- Switchable gain (12dB)
- Max. output voltage +20 dB
- Soft ground lift
Specifications
Description
PAN 02 PRO
The Palmer PAN02 PRO is an active DI box with outstanding additional functions. These include an unbalanced XLR input, in addition to the 3-way attenuator -10, -20, -30 dB and a switchable gain of 12 dB, connected with a maximum output voltage of +20 dBu. The ground lift switch has a "lift" position allowing adjustments between a "soft and hard grounding" . The balanced output is achieved with a high quality transformer in the Mumetall housingthat was specially developed for this purpose. The PAN02 PRO can be powered either with a 9 V battery or 48 V phantom power. A two-colour LED indicates which source supplies the power.
Downloads
Name | Type | Format | File size | ||
|---|---|---|---|---|---|
| PAN02PRO Bedienungsanleitung | Bedienungsanleitung | 883.79 KB | |||
| Palmer REACH-Erklärung Adam Hall GmbH | REACH-Erklärung | 493.71 KB | |||
| Palmer RoHS-Bestätigung Adam Hall GmbH | RoHS-Bestätigung | 197.63 KB | |||
| Palmer Herstellererklärung PALMER | Herstellererklärung | 66.79 KB | |||
| Product Images | Images & Artwork | .zip | - |
